1802 – The Four Courts, Inns Quay, Dublin

Architect: James Gandon

4courtss_lge

0844

2159214621452103209920414courtse_lge4courtse_lge4courts_lge4courts_arms_lge4courts_portico2_lge4courts_portico_lge4courts_section_lge4courts_section_lge03900091395139824190002019213342186170117281728256625672562

One of the landmarks of Dublin with its large drum and shallow dome, and visible all along the Liffey, the Four Courts derives its names from the four divisions that traditionally were the judicial system in Ireland. These were: Chancery, King’s Bench, Exchequer, and Common Pleas.

027

Originally, part of the building was designed by Thomas Cooley with a revised later scheme being developed by James Gandon to incorporate the earlier work. The original plan of the western block designed by Thomas Cooley consisted of a number of separate ‘houses’, each with its own entrance and stairwell. The eastern block designed by Gandon was one building with complete internal access. This can be seen on the plan below with Cooley’s block on the left.

The building’s main feature is the dome and main portico. The portico and pediment are a shallow projection from the centre block but Gandon created a semi-circular recess under the pediment bringing the entrance into the building.

0844

Described in 1837, “The courts are held in a magnificent structure, commonly called the Four Courts, situated on the north side of the river, having Richmond and Whitworth bridges at its eastern and western extremities; it consists of a central pile, 140 feet square, containing the courts, and two wings, in which are most of the offices connected with the despatch of legal business: these, with the centre, form two quadrangles. The front of the building consists of a boldly projecting central portico of six Corinthian columns on a platform, to which is an ascent by five steps, and supporting a highly enriched cornice surmounted by a triangular pediment, having on the apex a statue of Moses, and at the ends those of Justice and of Mercy. Through this portico is the principal entrance into the great circular hall, opposite to which is a passage to apartments connected with the courts, and on each side are others leading to the two quadrangles. In the intervals between these four passages are the entrances to the four chief courts; the Chancery on the north-west, the King’s Bench on the north-east, the Common Pleas on the south-east, and the Exchequer on the south-west.

The Rolls’ Court is held in an apartment in the northern part of the central building, between the Courts of Chancery and King’s Bench, where also are other apartments used as a law library and a coffee-room. The eastern wing, which forms the northern and eastern sides of one quadrangle, is appropriated to the offices belonging to the Common Pleas and some of those of the Chancery, the remainder of which, with the King’s Bench and Exchequer offices, are in the northern and western sides of the other wing. A new building, for a Rolls’ Court and a Nisi Prius Court, has been erected between the northern side of the main building and Pill-lane, on a piece of ground purchased for the purpose of isolating the courts, in order to diminish the risk of fire, and to provide additional accommodation for the augmentation of legal proceedings. This stately and sumptuous structure was begun by Mr. Thomas Cooley, architect, and completed by Mr. Gandon, at an expense of about £200,000, and the whole of the sculpture was executed by Mr. Edward Smith, a native artist.”

027

The interior of the Four Courts was reconstructed after the Civil War and the interior rearranged. The central rotunda above is as Gandon designed it with the four main courtrooms opening off it diagonally. This dramatic public space soars up into the drum creating a sombre and awe inspiring venue for the administration of the law. Described in the 1830s, before destruction, the hall had an elaborate interior: “The hall is lighted by a dome containing eight windows between which are colossal statues of Liberty, Justice, Wisdom, Law, Prudence, Mercy, Eloquence, and Judgment. A rich frieze of foliage rises above these statues and extends around the dome; in it are medallions of eight eminent law givers, viz Moses, Lycurgus, Solon, Numa, Confucius, Alfred, Mancha-Capac and Ollamh-Fodhla. Around the hall are columns of the Corinthian order with an entablature and an attic pedestal. Eight sunk panels in the piers correspond with the eight openings below and in the panels over the entrances into the courts are bas reliefs representing William the Conqueror establishing Courts of Justice Feudal Laws; King John signing Magna Carta; Henry II receiving the Irish Chieftains; and James I abolishing the Brehon law.”

Like all of Gandon’s buildings, the Four Courts was completed with excellent sculpture by Edward Smyth. On the main pediment, Moses is flanked by Justice and Mercy with Wisdom and Authority also present. Trophies of arms are placed over the triumphal arches in the arcades but they had been emasculated with the crowns replaced by balls.

Destroyed during the Irish Civil War of 1921-22, the building has since been restored externally although it was remodelled and rearranged internally. The only external changes was the removal of one bay from each of the side blocks so that they no longer project beyond the arcades as was originally intended by Gandon and shown in the plan above.
